Description: 3-way vented box
Drive Units: 1 x 25mmØ metal dome tweeter
1 x 150mmØ woven Kevlar cone midrange
2 x 165mmØ paper/Kevlar cone bass
Frequency Response: 45Hz – 20kHz ± 2dB on reference axis
Sensitivity: 89dB SPL (2.83v at 1m)
Nominal Impedance: 8O
Crossover Frequencies: 350Hz & 4kHz
Power Handling: 50W – 200W into 8O on unclipped programme
Max Cable Impedance: 0.1O
Dimensions:
- Height = 1015mm (40.0 inches)
- Width = 238mm (9.4 inches)
- Depth = 344mm (13.5 inches)
